Product Overview
Hikvision DS-2TD4137T-9/W Thermographic Thermal & Optical Bi-spectrum Network Speed Dome is applied to manufacture process supervision of pyrophoric materials in factories, electric substation, and hydropower station. The accurate temperature measurement system sends you alarms to protect you from property loss.
General Information
Name : Hikvision DS-2TD4137T-9/W 4MP Thermographic Thermal and Optical Bi-Spectrum Speed Dome IP Camera, 9mm Lens, White , Hikvision
Category : PTZ Security Cameras
UPC Code : 842571139792
Country of Origin : CN. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : HX-TD4137T9
Manufacturer : Hikvision
Manufacturer Part Number : DS-2TD4137T-9/W
Product Model : DS-2TD4137T-9/W
Product Type : Network Camera
Technical Information
Effective Camera Resolution : 4MP
Field of View : 56.6° × 33.7° (H × V) to 1.8° × 1.0° (H × V)
Lens Type : Varifocal
Maximum Aperture : f/1
Maximum Frame Rate : 25fps
Minimum Focal Length : 6mm
Optical Zoom : 40x
Video Formats : H.264, H.265, MJPEG
Video Resolution : 384 x 288
Camera
Connectivity Technology : Wired
Image Sensor Type : CMOS
Wide Dynamic Range : Yes
Certifications
Ingress Protection Rating : IP66
TAA Compliant : No
Display & Graphics
Maximum Video Resolution : 2688 x 1520
Environmental Conditions
Maximum Operating Temperature : 149°F (65°C)
Minimum Operating Temperature : -40°F (-40°C)
Operating Humidity : 0.95
Exposure
Longest Shutter Speed : 1 Second
Shortest Shutter Speed : 1/30000 Second
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Focal Length : 9 mm
Lens Included : Yes
Maximum Focal Length : 240 mm
Maximum Thermal Focal Length : 8.89mm
Minimum Aperture : f/4.6
Network & Communication
Remote Management : Yes
Physical Characteristics
Durability : Dustproof, Waterproof
Power Description
Input Voltage : 24V DC, 48V DC
Product Information
Mount Type : Pole Mount, Vertical Mount
Storage
Storage Type : Memory Card
Miscellaneous
Country of Origin : CN
