Product Overview
This Genesis® cable features 8 stranded 22 AWG copper conductors, an overall foil shield with a drain wire, and a plenum rating. Choose this cable for a dependable connection for security, controls, audio, and other low-voltage applications.
General Information
Name : Genesis 32071112 22/8 Stranded Shielded Plenum Cable, CL3P, FPLP, CMP, FT6, 1000' (304.8m), REELEX Pull Box, Natural White , Genesis
Category : Stranded Plenum Shielded Cables
UPC Code : 619172022507
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : WG-32071112
Brand Name : Genesis
Manufacturer : Genesis Cable
Manufacturer Part Number : 32071112
Packaged Quantity : 1
Product Model : 32071112
Product Name : 32071112 Control Cable
Product Type : Access & Security Cable
Weight (Approximate) (g) : 13154.179
Technical Information
American Wire Gauge : 22AWG
Cable Listing : CL3P, CMP, FT6
Cable Rating : Plenum
Cable Type : Multi-conductor/Multi-pair
Core/Cladding Diameter : 22/8
Device Supported : Burglar Alarm, Intercom, Phone
Impedance : 51 ohms
Jacket Type : Riser
Material : Bare Copper
Number of Conductors : 8
Number of Pairs : 4
Shielding : Yes
Solid or Stranded : Stranded
Physical Characteristics
Cable Length : 1000'
Cable Length (mm) : 304800
Color : Natural
Insulation Material : LS-PVC
Package Type : REELEX Pull Box
Weight (Approximate) : 29 lb
Warranty
Limited Warranty : 3 Year; 3-for-1
Miscellaneous
Country of Origin : United States
Environmental Certification : RoHS
Environmentally Friendly : Yes
Features : Stranded
Indoor/Outdoor : Indoor
TAA Compliant : Yes
