Product Overview
MaxiiPower Vi2508 and Vi2516 midspans are designed to meet the most demanding IP camera data and PoE requirements at extended distances. They are fully manageable and provide up to 37W per port, with no power sharing. The Vi2500 series provide extended distance transmission over UTP using Vigitron's unique Symmetric Bandwidth (SBW) technology. With only a transceiver and no additional power source at the camera site, the Vi2500 series can provide full 802.3.af, 802.3at on all ports. In addition, they can provide up to 74W on each ports 1 through 4. for high power applications such as PTZ cameras. They are fully transparent to the Ethernet network and higher layer protocols, and require no IP setting or configurations. The PoE controller provides auto mode with no programing required. The PoE is fully manageable by an easy-to-use Windows based GUI that can be accessed via direct connection to the USB port or remotely over network connections. It also operates in auto mode with no programing required. Standard accessory client software provides full security, discovery for all Vigitron Midspans' set up and individual port monitoring. The built-in Ethernet extender technology simplifies the installation and lowers the cost of the system by eliminating the need for standard PoE midspans with far limited PoE power and protection capability. MaxiiPower midspans provide status LED's to indicate power and transmission status to indicate potential problem areas. The PoE is fully manageable by an easy to use GUI that can be accessed via direct connection to the USB port or remotely over network connections. The Vi2508S and Vi2516S provide input connectors for redundent power supplies (RPS) for extra reliability. They need to be used with Vi2301A or Vi2701TX at the camera side.
General Information
Name : Vigitron Vi2516 MaxiiPower 16-Port PoE UTP Ethernet Extender , Vigitron
Category : PoE Extenders
UPC Code : 841144100191
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : VG-VI2516
Brand Name : Vigitron
Full Duplex : Yes
Housing Material : Extruded Aluminum
Manufacturer : Vigitron, Inc
Manufacturer Part Number : VI2516
Packaged Quantity : 1
Product Line : MaxiiPower
Product Model : Vi2516
Product Name : 16-port Extended UTP Ethernet Midspan
Product Type : PoE Injector
Weight (Approximate) (g) : 4989.516
Environmental Conditions
Operating Relative Humidity (H-H) : 0-95%
Operating Temperature (T-T) : -40-167°F
Storage Temperature (T-T) : -40-85°F
Interfaces/Ports
Input Ports : 16 x 10/100Base-TX, USB
Output Ports : 16 x 10/100Base-TX
Media & Performance
Network Technology : 16 x 10/100Base-TX, USB
Physical Characteristics
Color : Black
Depth : 12"
Depth (mm) : 304.8
Form Factor : Rack Mount
Height : 1.8"
Height (mm) : 44.45
Weight (Approximate) : 11 lb
Width : 17"
Width (mm) : 431.8
Power Description
Input Voltage : 110V AC, 220V AC
Input Voltage (V AC) : 110, 220
Maximum Input Current : 6.50 A
Maximum Input Current (A) : 6.5
Maximum Output Power : 600W
Maximum Output Power (W) : 600
Maximum Output Voltage : 56V DC
Maximum Output Voltage (V DC) : 56
Minimum Frequency : 50 Hz
Product Information
Length : 3.7"
Warranty
Limited Warranty : Lifetime
Miscellaneous
Certifications & Standards : CE, IEEE 802.3 af, IEEE 802.3 at
Compatibility : IP Cameras, VoIP Phones, Wireless Access Points
Country of Origin : US
Environmental Certification : RoHS, WEEE
Environmentally Friendly : Yes
Package Contents : <ul><li>16-port Extended UTP Ethernet Midspan</li><li>Mounting Brackets for Front or Rear Installations</li><li>Rubber Feet for Desk Applications</li><li>Molded IEC 7 ft. (200 cm) Power Cord</li></ul>
TAA Compliant : No
