TP-Link TL-SG2428P JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+

Brand: TP-Link
ADI #:FP-TLSG2428P Model #: SG2428P  Name: TP-Link TL-SG2428P JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+
  • Flexible Full Gigabit 28-Port PoE Configuration: 24× PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports providing up to 30W per port and total PoE power budget of 250W, togetherW/ 4× Gigabit SFP slots for high-speed connections.
  • Integrated into Omada SDN: Omada SDN platform integrates network devices, including switches, access points & gateways with multiple control options offered - Omada Hardware controller or Omada software Controller. Standalone Mode also applies.
  • Cloud Access: Remote cloud access and Omada app brings centralized cloud management of theWhole network at different sites-all controlled from a single interface anywhere, anytime.
Image of FP-TLSG2428P

Product Overview

Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

General Information

Name : TP-Link TL-SG2428P JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+ , TP-Link
Category : Network Switches
UPC Code : 845973088682
Country of Origin : China. Country of origin is subject to change.

Specifications

General Information

ADI Part Number : FP-TLSG2428P
Brand Name : TP-Link
Manufacturer : TP-LINK Technologies Co., Ltd
Manufacturer Part Number : TL-SG2428P
NDAA Compliant : No
Product Line : JetStream
Product Model : TL-SG2428P
Product Name : JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+
Product Type : PoE, Managed

Technical Information

Media Type Supported : Optical Fiber, Twisted Pair
Power Consumption : 32.10W

I/O Expansions

Expansion Slot Type : SFP (mini-GBIC)
Number of SFP Slots : 4
Number of SFP+ Slots : 4
Number of Total Expansion Slots : 4

Interfaces/Ports

Modular : Yes
Network (RJ-45) : Yes
Port/Expansion Slot Details : 24 x Gigabit Ethernet PoE+, 4 x Gigabit Ethernet Expansion Slot
Total Number of Network Ports : 28

Management & Protocols

Manageable : Yes

Media & Performance

Network Technology : 10/100/1000Base-T, 1000Base-X

Network & Communication

Ethernet Technology : Gigabit Ethernet
Layer Supported : 4
Networking Standards : IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Physical Characteristics

Compatible Rack Unit : 1U
Depth : 8.7"
Depth (mm) : 220.98
Form Factor : Desktop Mount, Rack Mount
Height : 1.7"
Height (mm) : 43.942
Width : 17.3"
Width (mm) : 439.42

Power Description

Frequency : 50 Hz, 60 Hz
Frequency (Hz) : 50, 60
Input Voltage : 120V AC, 230V AC
PoE (RJ-45) Port : Yes
PoE Budget : 250W
PoE Budget (W) : 250
Power Consumption (W) : 32.100
Power Source : PoE, Power Supply

Warranty

Limited Warranty : 5-year
Limited Warranty (Second) : 5-year

Miscellaneous

Country of Origin : CN
Environmental Certification : RoHS
Environmentally Friendly : Yes
Package Contents : <ul> <li>JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+</li> <li>Power Cord</li> <li>Installation Guide</li> <li>Rackmount Kit</li> <li>Rubber Feet</li> </ul>
TAA Compliant : No
