Specifications
General Information
ADI Part Number : SO-O8FD1
Brand Name : Speco Technologies
Manufacturer : Speco Technologies
Manufacturer Part Number : O8FD1
NDAA Compliant : Yes
Packaged Quantity : 12
Product Line : Flexible Intensifier
Product Name : O8FD1
Product Series : Flexible Intensifier
Weight (Approximate) (g) : 650
Technical Information
Effective Camera Resolution : 8MP
Field of View : Horizonal: 110° Vertical: 57.5° Diagonal: 133.5°
HD Recording : Yes
Lens Mount Type : M12
Lens Type : Fixed
Maximum Aperture : F1.6
Maximum Focal Length (mm) : 2.8
Maximum Frame Rate : 30 fps
Minimum Focal Length : 2.8 mm
Night Vision : Yes
Night Vision Type : IR
Number of IR LEDs : 3
Power Consumption (PoE) (W) : 9
Video Formats : NTSC, PAL
Audio
Master (outer) Case Height (mm) : 340
Master (outer) Case Length (mm) : 425
Master (outer) Case Weight (g) : 12637
Master (outer) Case Width (mm) : 285
Shipping (Inner) Case Gross Weight (g) : 966
Shipping (inner) Case Height (mm) : 135
Shipping (inner) Case Length (mm) : 135
Shipping (inner) Case Net Weight (g) : 966
Shipping (inner) Case Width (mm) : 158
Shipping Weight (Approximate) (g) : 966
Battery Information
Operating Temperature (T-T) (°F) : -22 to 140
Camera
Image Sensor Type : CMOS
Night Vision Distance : 8.17 ft
Night Vision Distance (mm) : 30000
Wide Dynamic Range : Yes
Display & Graphics
Color Supported : Color, Monochrome
Effective Camera Resolution (Pixel) : 8000000
Maximum Video Resolution : 8MP
Minimum Illumination (lux) : 0
Number of Sensors : 1
Environmental Conditions
Maximum Operating Temperature : 140°F
Maximum Operating Temperature (°F) : 140
Minimum Operating Temperature : -22°F
Minimum Operating Temperature (°F) : -22
Operating Humidity : >95 % (non-condensing)
Storage Temperature (T-T) (°F) : -22 to 149
Exposure
Longest Shutter Speed : 1/2s
Minimum Illumination : 0.008 lux
Shortest Shutter Speed : 1/100000 s
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Focal Length : 2.8 mm
Lens Included : Yes
Maximum Focal Length : 2.80 mm
Network & Communication
Remote Management : Yes
Physical Characteristics
Color : Gray
Depth : 5"
Durability : Dustproof, Impact Resistant, Waterproof, Weather Resistant
Form Factor : Dome
Height : 3.5"
Height (mm) : 88.9
Package Type : Box
Weight (Approximate) : 1.43 lb
Width : 5"
Width (mm) : 120
Power Description
Input Voltage : 12V DC
Input Voltage (V DC) : 12
Product Information
Diameter : 4.7"
Length (mm) : 87.6
Mount Type : Ceiling Mount, Pole Mount, Wall Mount
Projection Lens
Minimum Focal Length (mm) : 2.8
Video
Horizontal Resolution : 3840
Maximum Frame Rate (fps) : 30
Miscellaneous
Country of Origin : China
Environmental Certification : EC, EU RoHS, REACH, WEEE
Environmentally Friendly : Yes
Features : 3D Digital Noise Reduction, Back Light Compensation (BLC), Day/Night, Digital Noise Reduction, Highlight Compensation (HLC), Human Detection, Mirror, Motion Detection, Password Protection, Region of Interest, Vehicle Detection
Impact Protection Rating : IK10
Indoor/Outdoor : Indoor, Outdoor
Ingress Protection Rating : IP67
Package Contents : Camera, Screws, QSG, CD, Drill Template, Junction Box
