Lantronix TN-SFP-OC3S8-C41 MSA Compatible CWDM SFP Module, 100Base-FX/OC-3 Singlemode (LC) with DMI 1410nm, 80km

Brand: Lantronix
ADI #:P6-SFPOC3S8C Model #: TN-SFP-OC3S8-C41  Name: Lantronix TN-SFP-OC3S8-C41 MSA Compatible CWDM SFP Module, 100Base-FX/OC-3 Singlemode (LC) with DMI 1410nm, 80km
  • Coarse Wavelength Division Multiplexing (CWDM) ITU Grid Compliant Wavelengths
  • Hot-Pluggable SFP Footprint Duplex LC Optical Transceiver
  • Digital Diagnostic Function (DMI)
Image of P6-SFPOC3S8C

Product Overview

SFP 100Base-FX/OC-3 single mode (LC) with DMI 1410nm Link Budget- 29.0 dB.

General Information

Name : Lantronix TN-SFP-OC3S8-C41 MSA Compatible CWDM SFP Module, 100Base-FX/OC-3 Singlemode (LC) with DMI 1410nm, 80km , Lantronix
Category : SFP Modules
UPC Code : 648177037049

Specifications

General Information

ADI Part Number : P6-SFPOC3S8C
Brand Name : Lantronix
Manufacturer : Lantronix, Inc
Manufacturer Part Number : TNSFPOC3S8C41
Maximum Distance : 262467.19'
Product Model : TN-SFP-OC3S8
Product Name : TN-SFP-OC3S8-Cxx SFP Module
Product Series : TN-SFP-OC3S8-Cxx
Product Type : SFP

Technical Information

Fiber Optic Mode : Single-mode
Media Type Supported : Optical Fiber
Power Consumption : 0.66W

Certifications

TAA Compliant : Yes

Interfaces/Ports

Number of Ports : 1

Media & Performance

Network Technology : 100Base-CWDM, 100Base-FX/OC-3

Network & Communication

Ethernet Technology : 10 Gigabit Ethernet

Physical Characteristics

Depth : 2.2"
Form Factor : Hot-pluggable
Height : 0.3"
Width : 0.5"

Power Description

Input Voltage : 3.3V
Plug/Connector Type : LC

Warranty

Limited Warranty : Lifetime

Miscellaneous

Compatibility : MSA Compliant
Country of Origin : TW
Environmental Certification : REACH, RoHS, WEEE
Environmentally Friendly : Yes
