Product Overview
Unmanaged Hardened Fast Ethernet Media Converter
(1) 100Base-TX Port + (1) 100Base-FX Port
The E-100BTX-HT Series is a Hardened Ethernet stand-alone media converter that provides an interface between 100Base-TX ports and 100Base-FX ports, allowing users to integrate fiber optic cabling into extreme 100Base-TX copper environments, by supporting an operating temperature range of -25°C to 65°C. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
General Information
Name : Lantronix E-100BTX-FX-05(HT)-OZ E-100BTX Series 100Mbps Transmitter to Fiber Optic High Temperature Converter, Without Ounce Power Supply , Lantronix
Category : Media Converters
UPC Code : 648177045358
Specifications
General Information
ADI Part Number : P6-BTF5HTOZ
Manufacturer : Lantronix, Inc
Manufacturer Part Number : E-100BTX-FX-05(HT)-OZ
Maximum Distance : 1.24 Mile
Packaged Quantity : 2
Product Model : E-100BTX-FX-05(HT)
Product Type : Transceiver/Media Converter
Technical Information
Fiber Optic Mode : Multimode
Media Type Supported : Optical Fiber, Twisted Pair
Certifications
TAA Compliant : Yes
Interfaces/Ports
Number of Network (RJ-45) Ports : 1
Number of Ports : 2
Number of ST Ports : 1
Media & Performance
Fiber Optic Wavelength : 1300 nm
Network Technology : 100Base-FX, 100Base-TX
Network & Communication
Ethernet Technology : 10 Gigabit Ethernet
Power Description
Input Voltage : 120V AC, 230V AC
Power Source : AC, DC
Warranty
Limited Warranty : Lifetime
Miscellaneous
Environmental Certification : REACH, RoHS, WEEE
Environmentally Friendly : Yes
Package Contents : E-100BTX-FX-05(HT) Transceiver/Media ConverterPower Supply - Australia
