Product Overview
Altronix NetWay1D Single Port Midspan Injector provides Hi-PoE (60W) power and passes data for PoE compliant device. PoE device may be located up to 100m (328 ft.) from the unit.
General Information
Name : Altronix NetWay1D Single-Port Midspan Injector, PoE/PoE+/Hi-PoE or 56VDC Auxiliary Output , Altronix
Category : PoE Injectors
UPC Code : 782239952762
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : AX-NET1D
Brand Name : Altronix
Manufacturer : Altronix Corporation
Manufacturer Part Number : NETWAY1D
Product Line : NetWay
Product Model : NetWay1D
Product Name : Single Port Hi-PoE Injector for Standard & Enhanced Power Network Infrastructure
Product Series : NetWay
Product Type : PoE Injector
Certifications
NDAA Compliant : Yes
Environmental Conditions
Operating Temperature (T-T) : -22-122°F
Storage Temperature (T-T) : -22-185°F
Interfaces/Ports
Input Ports : 10/100/1000Base-T
Output Ports : 10/100/1000Base-T
Media & Performance
Data Transfer Rate : 10 Mbps, 100 Mbps, 1000 Mbps
Network Technology : 10/100/1000Base-T
Network & Communication
Networking Standards : IEEE 802.3af
Physical Characteristics
Depth : 7.2"
Height : 1.7"
Width : 4.1"
Power Description
Input Voltage : 120V AC, 230V AC
Maximum Frequency : 60 Hz
Maximum Input Current : 1.20 A
Maximum Output Power : 60W
Maximum Output Voltage : 56V DC
Warranty
Limited Warranty : Lifetime
Miscellaneous
Certifications & Standards : CE, cULus, IEEE 802.3af, IEEE 802.3at, UL
Compatibility : Altronix eBridgePlus Receivers, IP Camera
Country of Origin : US
Environmental Certification : RoHS
Environmentally Friendly : Yes
